1450/1550/1660nm 1x3 Raman WDM Module with ABS Box

Brand Name : GEZHI or OEM

Model Number : GZ-1x3-RWM

Certification : CE RoHS,ISO9001

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000Channel per month

Delivery Time : 5-8 work days

Packaging Details : Paper box

Operating Wavelength : 1450/1550/1660nm

Port : 1x3

Fiber Length : 0.5m 1.0m or customize

Connector : LC/UPC SC/UPC or customize

Warranty : 3 Years

Application : WDM System

Contact Now

Product Overview of 1x3 Raman WDM Module

1450/1550/1660nm 1x3 Raman WDM Module with ABS Box

Raman WDM Module

The Raman Wavelength Division Multiplexer (Raman WDM) Module is manufactured by using thin-film filter technology, it used to separate and combine different signal wavelengths at 1450nm, 1550nm, and 1660nm (or 1650nm). Raman Filter WDM with low insertion loss and high isolation Characteristic. It's widely used in Raman DTS systems or other fiber test or measurement systems.

Features & Applications of 1x3 Raman WDM Module

Features:

Telcordia GR1221,RoHS Compliant
Optical path epoxy free and excellent thermal stability
Low insertion loss and high isolation
Wide and flat passband

Applications:

FTTX on line testing
WDM System
Enterprise networks

Specifications of 1x3 Raman WDM Module

Paramenter Unit Value
Operating Wavelength nm 1450/1550/1660
Center Wavelength nm 1450 1550 1650
Bandwidth nm 1260-1500 1535-1565 1600-1670
Insertion Loss dB ≤1.4
Isolation (Adjacent channel) dB ≥60 ≥45 ≥60
PDL dB ≤0.2
PMD ps ≤0.2
Directivity Singlemode dB ≥50
Multi mode dB ≥35
Return Loss Singlemode dB ≥45
Multi mode dB ≥35
Optical Power mW ≤500
Operating Temperature Range ℃ -10 to 70
Operating Temperature Range ℃ -40 to +85
Package (L x W x H) mm 100 x 80 x 10

Test Environment

1450/1550/1660nm 1x3 Raman WDM Module with ABS Box 1450/1550/1660nm 1x3 Raman WDM Module with ABS Box 1450/1550/1660nm 1x3 Raman WDM Module with ABS Box
1450/1550/1660nm 1x3 Raman WDM Module with ABS Box

Odering Information of 1x3 Raman WDM Module
Type Package Specification Fiber Type

Fiber

Diameter

Fiber

Length

 Connector
RWM =Roman WDM Module A1 =ABS box 100x80x10mm A2 =ABS box 120x80x18mm X=Others

S9 =9/125

M5 =50/125 M6 =62.5/125

25 =250um

90 =900um

20 =2.0mm

30 =3.0mm

X=Others

05 =0.5m

10 =1.0m

15 =1.5m

X=Others

00 =none

LP =LC/UPC

LA =LC/APC

SP =SC/UPC

SA =SC/APC

FP =FC/UPC

FA =FC/APC

X=Others

FAQ
Q1:Can I have a sample order? What is your MOQ of 1x3 Raman WDM Module?
A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms of 1x3 Raman WDM Module?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time of 1x3 Raman WDM Module?
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
